Unwind-Max unwind dia.700mm; Air expanding mandrel 3"
Web guide-Maxcess Web guide ( Edge position control )
Flat bed die cutting-Eye mark sensor, height of the blade 9.5mm ( with upper blade and the bottom blade )
Rewind-Single rewind, Max unwind dia.700mm; Air expanding mandrel 3"
Waste matrix-Max unwind dia.600mm; Air expanding mandrel 3"
|
NO. |
Purchase Items included in the offer |
UNIT |
|
1 |
Unwind-Max unwind dia.700mm; Air expanding mandrel 3" |
1 |
|
2 |
Web guide-Maxcess Web guide ( Edge position control ) |
1 |
|
3 |
Flat bed die cutting-Eye mark sensor, height of the blade 9.5mm ( with upper blade and the bottom blade ) |
1 |
|
4 |
Rewind-Single rewind, Max unwind dia.700mm; Air expanding mandrel 3" |
1 |
|
5 |
Waste matrix-Max unwind dia.600mm; Air expanding mandrel 3" |
1 |
Parameter:
|
1 |
Max Speed |
400 repeats/min |
|
2 |
Accuracy of Cutting |
±0.15mm |
|
3 |
Max Machine Web Width |
330mm |
|
4 |
Min slitting max-width='100%' width (Option) |
16mm |
|
5 |
Max Unwinding Dia. |
φ700mm |
|
6 |
Max Rewinding Dia. |
Φ700mm |
|
7 |
Total Machine Consumable |
14KW |
|
8 |
Overall Diameter(L×W×H) |
2700mm×1300mm×1500mm |
|
9 |
Weight |
3000KG |
|
10 |
Power Supply |
AV,380V,50HZ |
|
11 |
Air Supply |
0.4~0.6 MPa |
Web Path:
1. Mother reel end photocell with automatic stop. 2. Full rotary flexo printing module support sport varnishing/cold foil 3. Die cut unit able to work full rotary mode and semi rotary mode. 4. Precision cutting to reduce waste
1.Unwinder withClosed loop tension control.Electronic web guide with ultrasonic edge guide sensor. 2. FullServo driven with exact web tension control,easy to operate,Minimizes waste. 3.Internet fault diagnostics. 4.This is modular design which can be combined with Flexo station,Flat bed silk screen and hotfoil station and etc. 5.One single pass ,improving the finishing quality,ensuring better results and better productivity for converters. TechnicalParameter:
Unwind-Max unwind dia.700mm; Air expanding mandrel 3" Web guide-Maxcess Web guide ( Edge position control ) Flat bed die cutting-Eye mark sensor, height of the blade 9.5mm ( with upper blade and the bottom blade ) Rewind-Single rewind, Max unwind dia.700mm; Air expanding mandrel 3" Waste matrix-Max unwind dia.600mm; Air expanding mandrel 3"
